15. Slide the cardboard box over the chassis, making sure that the arrows on the box point up and the
pallet fasteners to secure the cardboard box to the wooden pallet are near the bottom.
16. Attach the cardboard box to the wooden pallet by screwing two screws into each of the four pallet
fasteners. See Figure 173 on page 309.
Figure 173: Attaching the MX10008 to the Pallet
17. Write the RMA number on the exterior of the box to ensure proper tracking.
Packing MX10008 Components for Shipping
Before you begin packing a router component, ensure that you have the following parts and tools available:
•
Antistatic bag, one for each component
•
Electrostatic discharge (ESD) grounding strap
CAUTION: Do not stack router components. Return individual components in separate
boxes if they do not fit together on one level in the shipping box.
309
