CAUTION: Do not stack SFBs on top of one another or on top of any other
component.
Storing Line Cards, RCBs, and SFBs
You must store line cards, RCBs, and SFBs either in the chassis or in a spare shipping container, horizontally
and sheet-metal side down. Do not stack these units on top of one another or on top of any other
component. Place each unit separately in an antistatic bag or on an antistatic mat placed on a flat, stable
surface.
NOTE: Because these units are heavy, and because electrotatic bags are fragile, inserting the line
card into the bag is best done by two people.
To insert a line card, an RCB, or an SFB into an electrostatic bag:
1. Hold the unit horizontally with the faceplate toward you.
2. Have the second person slide the opening of the electrostatic bag over the connector edge and then
pull the bag to cover the unit.
If you must insert a line card, an RCB, or an SFB into a bag by yourself:
1. Lay the unit horizontally on an antistatic mat that is on a flat, stable surface with the sheet metal side
down.
2. Orient the unit with the faceplate toward you.
3. Carefully insert the connector edge into the opening of the bag and pull the bag toward you to cover
the unit.
SEE ALSO
Installing an MX10008 Switch Fabric Board | 251
247
