Juniper MX10008 User Manual

MX10008 Components and Configurations
Table 4 on page 31 lists the four hardware configurations for an MX10008 modular chassis—base (AC and
DC versions), and redundant (AC and DC versions)—and the components included in each configuration.
Table 4: MX10008 Hardware Configurations
Configuration ComponentsRouter Configuration
•
Chassis, including power bus
•
One Routing and Control Board
•
One Routing Control Board cover
•
Two fan tray controllers (JNP10008-FAN-CTRL or JNP10008-FTC2)
•
Two fan trays (JNP10008-FAN and JNP10008-FAN2)
•
Three AC power supplies (JNP10K-PWR-AC or JNP10K-PWR-AC2)
•
Three power supply covers
•
Five Switch Fabric Boards (SFBs)
•
One SFB cover
•
Eight line card covers
Base AC configuration
MX10008-BASE
•
Chassis, including power bus
•
One Routing and Control Board
•
One Routing Control Board cover
•
Two fan tray controllers (JNP10008-FAN-CTRL or JNP10008-FTC2)
•
Two fan trays (JNP10008-FAN and JNP10008-FAN2)
•
Three DC power supplies (JNP10K-PWR-DC, JNP10K-PWR-DC2, or
JNP10K-PWR-AC2)
•
Three power supply covers
•
Five Switch Fabric Boards (SFBs)
•
One SFB cover
•
Eight line card covers
Base DC configuration
MX10008-BASE
•
Chassis, including power bus
•
Two Routing and Control Boards
•
Two fan tray controllers (JNP10008-FAN-CTRL or JNP10008-FTC2)
•
Two fan trays (JNP10008-FAN and JNP10008-FAN2)
•
Six AC power supplies (JNP10K-PWR-AC or JNP10K-PWR-AC2)
•
Six SFBs
•
Eight line card covers
Redundant AC configuration
MX10008-PREMIUM
31
