CAUTION: Any USB memory product not listed as supported for the MX10008 router
has not been tested by Juniper Networks. The use of any unsupported USB memory
product could expose your device to unpredictable behavior. Juniper Networks Technical
Assistance Center (JTAC) can provide only limited support for issues related to
unsupported hardware. We strongly recommend that you use only supported USB flash
drives.
CAUTION: Remove the USB flash drive before upgrading Junos OS or rebooting an
MX10008 router. Failure to do so could expose your device to unpredictable behavior.
NOTE: USB flash drives used with the MX10008 router must support USB 2.0 or later.
Management Port Connector Pinouts for the MX10008 Router
The 1000BASE-T RJ-45 management ports use an RJ-45 connector to connect either to the control plane
and management network in an MX10008 router, or to a management device for out-of-band management.
Table 49 on page 127 provides the pinout information of the RJ-45 management port connector. An RJ-45
cable is supplied with the MX10008 router.
Table 49: RJ-45 Management Port Connector Pinouts for the MX10008 Router
DescriptionSignalPin
Transmit/receive data pair 1TRP1+1
Transmit/receive data pair 1TRP1–2
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 3TRP3+4
Transmit/receive data pair 3TRP3–5
Transmit/receive data pair 2TRP2–6
