Fan Tray 1 Fan 19 OK 7800 Spinning at normal speed
Fan Tray 1 Fan 20 OK 6450 Spinning at normal speed
Fan Tray 1 Fan 21 OK 7650 Spinning at normal speed
user@host>
Two fan tray controller models and their associated fan trays are available. See Table 10 on page 51.
Table 10: Fan Tray Controller Specifications
JNP10008-FTC2JNP10008-FAN-CTRLSpecification
JNP10008-FAN2JNP10008-FANCorresponding fan tray model
Enhanced or standardEnhanced or standardChassis supported
19.2R115.1X53-D30Introduced in Junos OS Release
1.5 in. (3.81 cm)1.5 in. (3.81 cm)Height
6.5 in. (15.24 cm)6.5 in. (15.24 cm)Width
9.4 in. (23.88 cm)9.3 in. (23.62 cm)Depth
1.1 lb (0.5 kg)1.5 lb (0.68 kg)Weight
Airflow Direction in the MX10008 Router
The air intake to cool the chassis is located on the port (line card) side of the chassis. Air flows into the
chassis from the ports in the RCBs and line cards, through the switch fabric boards (SFBs), and exits from
the fan trays and the power supplies. This airflow is called port-to-FRU cooling or airflow out (AFO). See
Figure 23 on page 52.
