Keithley 3700 Series User Manual

Series 3700A System Switch/Multimeter Reference Manual Section 11: TSP command reference
3700AS-901-01 Rev. D/June 2018 11-393
Bit
Value
Description
B7
status.standard.POWER_ON
status.standard.PON
Set bit indicates that the instrument has been
turned off and turned back on since the last
time this register has been read.
Bit B7 decimal value: 128
B8-B15
Not used
Not applicable
As an example, to set bit B0 of the standard event status enable register, set
status.standard.enable = status.standard.OPC.
In addition to the above constants, standardRegister can be set to the numeric equivalent of the
bit to set. To set more than one bit of the register, set standardRegister to the sum of their
decimal weights. For example, to set bits B0 and B4, set standardRegister to 17 (which is the
sum of 1 + 16).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
Example 1
standardRegister = status.standard.OPC
+ status.standard.EXE
status.standard.enable = standardRegister
Uses constants to set the OPC and EXE bits
of the standard event status enable register.
Example 2
-- decimal 17 = binary 0001 0001
standardRegister = 17
status.standard.enable = standardRegister
Uses a decimal value to set the OPC and
EXE bits of the standard event status enable
register.
Also see
Event summary bit (ESB register) (on page C-10)
status.system.*
These attributes manage the TSP-Link
®
system summary register of the status model for nodes 1 through 14.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
32,767 (All bits set)
