Revision:1.0(2023-01-12)
111
Category Item Description
Document
sharing
service
IP Address Enter the ADT data source IP address of the ADT
application gateway in the eGateway server pre-
configuration.
Port Enter the SSL port of document sharing in the
eGateway server pre-configuration.
Image/Video/PDF
Report
Set the stored content.
/ Clear Clear the information that is entered currently.
Add Adds a shared service to the service list.
Update Completes and saves the setting or modification of
server parameters.
Delete Delete the selected service from the service list.
Set default server Select an item in the service list and tap Default. You
can see Y in the Default column.
Connect Verify whether the connection is normal.
Set Q-Path.
The system allows you to view data on a web browser. If you have bought the storage service of
the browser, visit the URL of the browser server and enter your user name and password
(provided by the browser provider) to view the data. You can use the browser to view the DICOM
data sent to the server.
The parameters are as follows:
Item Description
Advanced Allows you to set QView full sub URL and QView lite sub URL.
Generally, the default settings are used. After changing the settings,
click Apply to save the new settings.
Enable Direct Report
Allows you to tap the report button to access the Q-Path server.
Worksheet Only Specifies whether the Worksheet screen will appear directly when Q-
Path is opened.
Enter password in
worksheet
This item specifies whether to display the password editing box on the
worksheet editing screen.
Choose Report>Worksheet or Browse>Report>Worksheet. On the
Worksheet screen, enter your worksheet password and tap OK to
exit.
Password on End
Exam
Specifies whether to the worksheet password is required when the
examination is completed.
Diagnostic Ultrasound System
Service Manual
3 Installation
