9-9
2.3 To defog the windshield
Place the mode selector dial in the position. If
you wish to defog the windshield quickly, use the
fan speed dial to select the maximum fan speed
and use the temperature adjustment dial to select
the maximum temperature.
2.4 To ventilate the cab
Press the air selector switch to select outside air,
and place the mode selector dial in the position.
When the mode switches to air recirculation, the
indicator lamp in the switch goes out.
2.5 To cool the cab
Press the air conditioner switch to activate the air
conditioner, then use the temperature control dial to
set a comfortable temperature. The indicator lamp
will be illuminated while the air conditioner is
operating.
3 Cleaning the air filter
Clean the air filter every 6 months.
A dust clogged air filter may cause a poor air condi-
tioning performance and blower motor malfunction.
P. 1 2 - 8 6
Z21050
Z21052
Z21053
