13-11
1 Blade-type fuses
1.1 Removal and installation of lower panel in
front of assistant driver’s seat
1. Remove the lower panel in front of the assis-
tant driver’s seat.
2. Reinstall the lower panel by first aligning the
claws with the corresponding slots and then
pushing the panel forward.
1.2 Removal and installation of high-current
fuse box cover
1. Pry and release the two locks and remove the
cover.
2. To install the cover, push in the cover until the
two locks click.
Z21420
Z21421
