12-35

3. Add oil through the inspection plug hole until it

reaches the bottom of the hole.

4. Install the inspection plug.

6 Brake fluid

Have the brake fluid replacement performed by an

authorized dealer.

Recommended fluid:

Brake fluid SAE J1703

FMVSS No. 116, DOT3

Tightening

torque

110 ± 10 N·m (81 ± 7 ft.lbs.,

11 ± 1 kgf·m)

Inspection

intervals

At the time of pre-operational

check

Replacement

intervals

Every 24 months
