15-5
SUSPENSION SYSTEM
Suspension springs I ••••••
Check for broken springs and
tilt of vehicle body toward
either side.
–
U-bolts looseness • I
Every 30,000 km/
18,000 miles or
12 months
Check U-bolt nuts for loose-
ness.
Check at the first 1‚000 km/
600 miles after removing and
retightening U-bolt nuts.
–
BRAKING SYSTEM
Service brake pedal I ••••••
Check brake pedal play and
stroke.
12-64
Brake
performance
I••••••
Depress the brake pedal and
check that the brakes work
effectively and evenly on all
wheels.
12-64
Disc brake pad and
disc
••
Every 30,000 km/
18,000 miles or
12 months
Check disc brake pad and
disc for damage and wear.
–
Brake lining • •
Every 30,000 km/
18,000 miles or
12 months
Check lining for wear through
inspection hole.
–
Brake drum • •
Every 30,000 km/
18,000 miles or
12 months
Disassemble and check drum
for wear, crack and damage.
Parking brake lever
stroke
I••••••
Check parking brake lever
stroke.
12-65
Looseness, play
and damage of
brake system parts
••
Every 30,000 km/
18,000 miles or
12 months
Inspect brake lines and hoses
looseness, play and damage.
Inspect wheel cylinder and
brake master cylinder for
looseness, play and damage.
–
STEERING SYSTEM
Steering wheel play I ••••••
Turn steering wheel right and
left to measure play at steer-
ing wheel rim. Measure while
engine is running.
12-62
Steering wheel
operation
I••••••
Check that the steering wheel
does not vibrate or pull to one
side and that it is not unduely
heavy. Also make sure that
the steering wheel returns to
its neutral position smoothly.
12-63
Item
Time of inspection and maintenance
Working procedures
Ref.
page
Pre-operational checks
1st maintenance at
4,000 km/2,500 miles
Inspection interval
Every 10,000 km/
6,000 miles
Every 20,000 km/
12,000 miles
Every 30,000 km/
18,000 miles
Every 40,000 km/
24,000 miles
Every 50,000 km/
30,000 miles
