14-4 Service data
Service data
Description Standard value
Engine idling speed 650 rpm
Coolant quantity
Vehicles other than those
specified below
Approx. 14 liters
(14.8 qts)
Crew cab (with rear air
conditioner)
Approx. 15.1 liters
(16 qts)
Crew cab (with rear
heater)
Approx. 15.2 liters
(16.1 qts)
Brake pedal play (at center of pedal pad)
0.1 to 3 mm
(0.0039 to 0.12 in.)
Fully depressed brake pedal to floor clearance 10 mm (0.39 in.) or more
Parking brake lever stroke
(When pulled with a force of 294 N {66 lbs., 30 kgf}.)
7 to 9 notches
Steering wheel play (as measured on the
periphery of steering wheel)
When engine is turned off
10 to 20 mm
(0.39 to 0.79 in.)
When engine is idling
5 to 50 mm
(0.20 to 1.97 in.)
Tire tread groove depth 1.6 mm (0.06 in.) or more
Wheel nut tightening torque
440 to 540 N·m
(325 to 398 ft.lbs.,
45 to 55 kgf·m)
Tire inflation pressure
FEC52
LT215/85R16-10PR
(Load Range E)
550 kPa
(80 psi, 5.5 kgf/cm
2
)
FEC72
FEC92
215/75R17.5
124/123L
(Load Range F)
690 kPa
(100 psi, 7.0 kgf/cm
2
)
FG
LT235/85R16-10PR
(Load Range E)
550 kPa
(80 psi, 5.5 kgf/cm
2
)
FE_FG.book Page 4 Tuesday, February 8, 2011 4:00 PM
