Note: If a key is deleted then all the volumes created using that key are un-mounted. The same key is
required to re-mount the volume.
Volumes
Creates an encrypted file system (volume) on the device. The user must have Administrative privileges to create a
volume.
Creating Volume Using EFS File
Procedure:
1 Create an efs file. See Creating an EFS File on page 103 for instruction on creating the efs file.
2 Copy the keyfile and efsfile files to root of the microSD card. See USB Communication on page 55.
3 Touch Create Volume.
4 Touch Import.
5 Touch OK. The message Successfully Created the Volume appears briefly.
Creating a Volume Manually
Procedure:
1 Touch Create Volume.
2 Touch Manual.
3 Touch OK.
4 In the Enter Parameters To Create Volume text box, enter the parameters in the follow format:
<Volume Name> <Volume Storage Type> Key Name> <Mount Path> <Auto Mount> <Volume size>
where:
• <Volume Name> = name of the volume.
• <Volume Storage Type> = storage location. Options: internal or sdcrad.
• <Key Name> = name of the key to use when creating the volume.
• <Mount Path> = path where the volume will be located.
•
<Auto Mount> = Options: 1 = yes, 0 = no.
• <Volume size> = size of the volume in Megabytes.
Figure 85: Enter Parameter To Create Volume Dialog Box
5 Touch OK. The message Successfully Created the Volume appears briefly. If the size of the volume is very
large, a progress bar displays.
102 | Administrator Utilities
April 2015 | MN000887A01-B
