Bar Code Input
Use the Bar Code Input options to configure the Bar Code Scanner Input Plug-in for the profile.
Enabled
Enables or disables this plug-in. A check in the checkbox indicates that the plug-in is enabled.
Scanner Selection
Configures which scanning device to use for bar code data capture when the profile is active.
• Auto - The software automatically selects the 2D Imager.
• 2D Imager - Scanning is performed using the 2D Imager.
Decoders
Configures which bar code decoders are enabled or disabled. For best performance disable all unnecessary decoders.
Touch Decoders. The Barcode input screen appears. A check in the checkbox indicates that the decoder is enabled.
By default the most commonly used decoders are enabled (shown below with an asterisk). The supported decoders
are:
UPC-A* UPC-E0* EAN-13*
EAN-8* Code 128* Code 39*
Interleaved 2 of 5 GS1 DataBar* GS1 DataBar Limited
GS1 DataBar Expanded Datamatrix* QR Code*
PDF417* Composite AB Composite C
MicroQR Aztec* Maxicode*
MicroPDF USPostnet USPlanet
UK Postal Japanese Postal Australian Postal
Canadian Postal Dutch Postal US4state FICS
Codabar* MSI Code 93
Trioptic 39 Discrete 2 of 5 Chinese 2 of 5
Korean 3 of 5 Code 11 TLC 39
Matrix 2 of 5 UPC-E1
Press to return to the previous screen.
Decoder Params
Use Decode Params to configure individual decoder parameters.
• UPCA
- Report Check Digit - The check digit is the last character of the symbol used to verify the integrity of the
data. Enables or disables this option. A check in the checkbox indicates that the option is enabled (default -
enabled).
- Preamble - Preamble characters are part of the UPC symbol consisting of Country Code and System
Character. Select the appropriate option to match the host system.
DataWedge Configuration | 63
MN000887A01-B | April 2015
To Next Page
