Pin Signal Name Description
2 Cradle_IN* When grounded, the MC32N0 detects it is in the cradle.
3 DCD RS232 DCD (into MC32N0)
4 USB_N USB negative
5 USB_P USB positive
6 GND Ground/Return
7 BOTG_VBUS2 USB power out
8 USB_P2_7_SCTR USB ID
9 U1_TXD_RS232 RS232 TXD (out of MC32N0)
10 U1_RXD_RS232 RS232 RXD (into MC32N0)
11 U1_RTS_RS232 RS232 RTS (out of MC32N0)
12 U1_CTS_RS232 RS232 CTS (into MC32N0)
13 U1_DTR_RS232 RS232 DTR (out of MC32N0)
14 U1_DSR_RS232 RS232 DSR (into MC32N0)
15 VCC5_CAM 5V power to RS232 accessories
16 POWER_JACK_ACC Power into MC32N0.
MC32N0 Accessory Specifications
The following sections provide technical specifications for the MC32N0 accessories.
Single Slot Serial/USB Cradle CRD3000-1001R Technical
Specifications
Table 22: Single Slot Charge Cradle CRD3000-1001R Technical Specifications
Item Description
Dimensions
Height: 69.4 mm (2.73 in.)
Width: 102.5 mm (4.04 in.)
Depth: 88.9 mm (3.50 in.)
Weight 274 g (9.67 oz)
Input Voltage 5 VDC
Power Consumption 30 watts
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
Charging Temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity 0% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature.
Table continued…
Technical Specifications | 175
MN000887A01-B | April 2015
