3
-
CONTROLS
AND
INSTRUMENTS
Horn
switch
The
horn
switch
(1)
is
located
on
the
center
of
the
steering
wheel
shroud.
T
o
activate
the
horn,
place
the
key
switch
in
the
“ON”
po-
sition
and
push
the
horn
switch
down.
NHIL22CT00348AA
1
3-31
120
122
