7 - MAINTENANCE
2. Remove bulb (4) from the bulb retaining tabs.
NOTE: Replace with a 37R, 5 watt, double ended type bulb.
3. Insert the new bulb between the retaining tabs.
4. Install lenses and retaining screw.
NHIL15CT00595AA 4
External work light - Cab
The work lights (1) on the front and rear of the cab are
identical.
NHIL16CT00513AA 1
1. Remove the bulbs of the front and rear work lights, by
rotating the bulb housing (2) counterclockwise aligning
it with the groove.
NHIL16CT00514AA 2
2. Remove the bulb housing (1) and the wiring harness
connector (2).
NHIL16CT00515AA 3
7-62
