7 - MAINTENANCE
Front turn signal/hazard light bulb
To replace the top asher light bulb:
1. Remove the screw (1) in the center of the lenses and
remove the lenses (2) .
NHIL15CT00594AA 1
2. Push in on the bulb (3) and rotate bulb counter-clock-
wise in socket to remove.
NOTE: Replace with a P21 watt bulb.
3. Insert the new bulb into the socket and turn it clockwise
until the bulb locks into place.
4. Install lenses and retaining screw.
NHIL15CT00595AA 2
To replace the bottom light bulb:
1. Remove the screw (1) in the center of the lenses and
remove the lenses.
NHIL15CT00594AA 3
7-61
