3 - CONTROLS AND INSTRUMENTS
Left-hand side controls
Left-hand controls - Cab
NHIL22CT00242FA 1
Mechanical transmission
(1) Power Take-Off (PTO) gear lever
(optional)
(3) GSP lever (Optional) (5) Hydraulic Power Lift (HPL) down
speed control knob
(2) Range gear shift lever (4) Four Wheel Drive (FWD) lever (6) Mid PTO gear lever (Optional)
3-40
