5 - TRANSPORT OPERATIONS
Turn signal operation - Roll Over Protective Structure (ROPS)
The multifunction switch is located on the left-hand side
of the dash panel.
1. The turn signal lights will activate by moving the mul-
tifunction switch lever (1) forward for right turns and
rearward for left turns.
2. The key switch has to be in the "ON" position for the
turn signal to operate.
3. When signaling a turn, the designated tail amber light
(2) and the side hazard light (3) will ash and the tail
amber and the side hazard lights for the opposite side
of turning direction will illuminate continuously.
NHIL13CT00525AA 1
NHIL22CT00342AA 2
NHIL22CT00343AA 3
5-6
