Wheel tread settings
NOTE: Tread settings are measured from center of tire to center of tire.
Front wheel settings
Tire Type
Tractor Model
Setting
NOTE
Agricultural, (R1)
9.5-16 Front-Wheel Drive
1280 mm (50 in)
Not Adjustable
Turf, (R3)
28 x 8.50-15
Front-Wheel Drive
1209 mm (47.6 in)
Not Adjustable
(Dished In Only)
Industrial (R4)
12 x 16.5 Front-Wheel Drive
1392 mm (55 in)
Not Adjustable
(Dished In Only)
NOTICE: Never attempt to widen the tread setting by reversing front wheels on a front-wheel drive system.
NOTE: Torque front wheel bolts and nuts to: 176 – 196 N·m (130 – 145 lb ft).
Rear wheel settings
Tire Type
Tractor Model
Setting
NOTE
Agricultural, HI-Traction
Lug-Standard, (R1)
13.6 x 24, 8 PR TL
Front-Wheel Drive
1266.0 mm (49.8 in)
Not adjustable
(Dish In Only)
Turf, (R3)
41 x 14.00-20
1266 mm (50 in)
Front-Wheel Drive
Not adjustable
(Dish In Only)
Industrial, (R4) 17.5L x 24
- 8PR
Front-Wheel Drive
1320 mm (52.0 in)
Not adjustable
(Dish In Only)
NOTE: Torque rear wheel bolts and nuts to: 176 – 196 N·m (130 – 145 lb ft)
