5 - TRANSPORT OPERATIONS
Turn signal operation - Cab
The multifunction switch is located on the left-hand side
of the dash panel.
1. The turn signal lights will activate by moving the mul-
tifunction switch lever (1) forward for right turns and
rearward for left turns.
2. The key switch has to be in the "ON" position for the
turn signal to operate.
3. When signaling a turn, the designated rear amber light
(3) and the front side hazard light (2) will ash and the
tail amber and the side hazard lights for the opposite
side of turning direction will illuminate continuously.
NHIL13CT00525AA 1
NHIL22CT00344AA 2
NHIL22CT00345AA 3
5-5
