7 - MAINTENANCE
After îš¿rst 50 hours
Engine oil and oil îš¿lter - Change
WARNING
Jack stands can slip or fall over. Dropping, tipping, or slipping of machine or its components is pos-
sible.
DO NOT work under a vehicle supported by jack stands only. Park machine on a level surface. Block
wheels. Support machine with safety stands.
Failure to comply could result in death or serious injury.
W0069A
WARNING
Burn hazard!
Do not handle any service uid (engine coolant, engine oil, hydraulic oil, etc.) at temperatures that
exceed 49 °C (120 °F). Allow uids to cool before proceeding.
Failure to comply could result in death or serious injury.
W0330B
NOTE: Change the engine oil and îš¿lter after the îš¿rst 50 hours of operation, then every 300 hours thereafter.
To change the engine oil, do the following:
1. Place a suitable container beneath the drain opening
to catch the used oil. With the tractor engine off but
at normal operating temperature, remove the two drain
plugs, (1) and (2), located on both sides of the engine
oil pan. Install the plugs after draining the oil.
NHIL16CT00447AA 1
NHIL16CT00449AA 2
7-23
