General Information 14Service Manual – SC6500
™
Technical Specifications (As Installed and Tested On The Unit)
Advance Brand SC6500 Models
Model (with and without
EcoFlex)
40C 45C 48C
40D 45D 48D
Model No. 56414010
56414011
56414012
56414013
56414014
56414015
56414016
56414017
56414018
56414019
56414020
56414021
Voltage, Batteries V 36V 36V 36V
Battery Capacity (max) Ah 450 450 450
Protection Grade IPX3 IPX3 IPX3
Sound Pressure Level
IEC 60335-2-72: 2002 Amend.
1:2005, ISO 11201
dB(A)/20µPa 70 70 70
Sound Pressure level - KpA (IEC
60335-2-72, ISO 11201) Uncertainty
dB(A) 3.0 3.0 3.0
Gross Weight* - Cylindrical lbs / kg 3325 / 1508 3365 / 1526 3410 / 1547
Transportation Weight** -
Cylindrical
lbs / kg 2897 / 1314 2937 / 1332 2982 / 1353
Gross Weight* - Disc lbs / kg 3220 / 1460 3270 / 1483 3320 / 1506
Transportation Weight** - Disc lbs / kg 2792 / 1266 2842 / 1289 2892 / 1312
Maximum Wheel Floor Loading
(center front)
psi / kg/cm2 116 / 8.15 116 / 8.15 116 / 8.15
Maximum Wheel Floor Loading
(right rear)
psi / kg/cm2 81 / 5.69 81 / 5.69 81 / 5.69
Maximum Wheel Floor Loading (left
rear)
psi / kg/cm2 86 / 6.04 86 / 6.04 86 / 6.04
Vibrations at the Hand Controls
(ISO 5349-1)
m/s2 <1.12m/s2 <1.12m/s2 <1.12m/s2
Vibrations at the Hand Controls
(ISO 5349-1) Uncertainty
m/s2 .11 m/s2 .11 m/s2 .11 m/s2
Vibrations at the Seat (EN 1032) m/s2 <0.35m/s2 <0.35m/s2 <0.35m/s2
Vibrations at the Seat
(EN 1032) Uncertainty m/s2 0.035m/s2 0.035m/s2 0.035m/s2
Gradeability Transport 16% (9°) 16% (9°) 16% (9°)
Gradeability Cleaning 10.5% (6°) 10.5% (6°) 10.5% (6°)
Machine Length inch / cm 73.5 / 187
Machine Height
inch / cm 58.5 / 148.6
Machine Height (w/overhead guard) inch / cm 84 / 213
Machine Width at Rollers -
Cylindrical
inch / cm 47.5 / 121 53.5 / 136 55.5 / 141
Machine Width at Rollers - Disc inch / cm 42.5 / 108 51.5 / 131 52.5 / 133
Machine Width with Squeegee inch / cm 49 / 125 “F” 54 / 137 “G” 57 / 145 “H”
Minimum Aisle Turn Width inch / cm 84 / 214
