Page #190 background imageLoading...
Page #190 background image
Wheel System, Traction 190Service Manual – SC6500
Fault Code Table (Troubleshooting Chart)
The troubleshooting chart, provides the following information on each wheel drive controller fault:
Fault code
Fault name as displayed on the programmer’s LCD
The effect of the fault
Possible causes of the fault
Fault set conditions
Fault clear conditions.
Whenever a fault is encountered and no wiring or vehicle fault can be found, shut off KSI (Key Switch)
and turn it back on to see if the fault clears. If it does not, shut off KSI and remove the low current 35-pin
connector from the drive controller. Check the connector for corrosion or damage, clean it if necessary, and
re-insert it.
Note: Some of the codes listed in the table are for circuits that are not utilized on the SC6500.
Troubleshooting Chart
Flash
Code
#
Programmer LCD
Display/ Effect Of Fault
Possible Cause(s) Set/Clear Conditions
12 Controller Overcurrent
ShutdownMotor;
ShutdownMainContactor;
ShutdownEMBrake;
ShutdownThrottle;
FullBrake; ShutdownPump
1. External short of phase U,V, or
W motor connections.
2. Motor parameters are mis-
tuned.
3. Controller defective.
4. Speed encoder noise
problems.
Set: Phase current exceeded
the current measurement limit.
Clear: Cycle KSI.
13 Current Sensor Fault
ShutdownMotor;
ShutdownMainContactor;
ShutdownEMBrake;
ShutdownThrottle;
FullBrake; ShutdownPump.
1. Leakage to vehicle frame from
phase U, V, or W (short in
motor stator).
2. Controller defective.
Set: Controller current sensors
have invalid offset reading.
Clear: Cycle KSI.
14 Precharge Failed
ShutdownMotor;
ShutdownMainContactor;
ShutdownEMBrake;
ShutdownThrottle;
FullBrake; ShutdownPump.
1. External load on capacitor
bank (B+ connection terminal)
that prevents the capacitor
bank from charging.
2. See Monitor menu » Battery:
Capacitor Voltage.
Set: Precharge failed to charge
the capacitor bank to the KSI
voltage.
Clear: Cycle Interlock input
or use VCL function Enable_
Precharge.
15 Controller Severe
Undertemp
ShutdownMotor;
ShutdownMainContactor;
ShutdownEMBrake;
ShutdownThrottle;
FullBrake; ShutdownPump.
1. See Monitor menu » Controller:
Temperature.
2. Controller is operating in an
extreme environment.
Set: Heatsink temperature
below -40°C.
Clear: Bring heatsink
temperature above -40°C, and
cycle interlock or KSI.
