Electrical System 70Service Manual – SC6500
™
X29 Connects to M7 Left Side Broom Motor X27
Pin No. Wire ID
A BLK 18-3
B WHT/RED 18-1
X30 Connects to M8 Right Side Broom Motor X28
Pin No. Wire ID
A BLK 18-5
B WHT/RED 18-2
X32
Pin No. Wire ID
A VIO/BLK 18-1
B BRN/RED 18-1
C WHT/BLK 18-1
