Solution System 154Service Manual – SC6500
™
Specifications
Solution Flow Rates
Standard Flow Rates Override Flow Rates
1 bar 2 bars 3 bars 4 bars 5 bars
40” Disc .84 GPM 1.00 GPM 1.50 GPM 2.00 GPM 2.50 GPM
40” Cylindrical .70 GPM .84 GPM 1.00 GPM 1.50 GPM 2.50 GPM
45”/48” Disc 1.00 GPM 1.50 GPM 2.00 GPM 2.25 GPM 2.50 GPM
45”/48”
Cylindrical
.84 GPM 1.00 GPM 1.50 GPM 2.00 GPM 2.50 GPM
Component Specifications
Component Specifications
Solution Control Pump
Voltage - 36 VDC
Current Draw - 3.9 amps max.
Flow Rate - 3.3 GPM @ 2.75 amps with 20 psi inlet
pressure
Solution Solenoid Valve
Coil Voltage - 36 VDC
Coil Resistance - 74 ohms
Accessory Pump
Voltage - 36 VDC
Current Draw - 3.0 amps max.
Pressure Control Setting - 100 ±5 psi
Maximum Flow Rate - 1.6 gal/min
Detergent Pump
Voltage - 24 VDC
Flow Rate - 87 ±3 ml/min
Shop Measurements
Solultion Solenoid (L1) resistance at room temperature: 93 ohms
Chemical Metering Pump (M13, M16): 36.6 ohms
