6 Installation
6 - 6
NX-series EtherCAT Coupler Unit User’s Manual (W519)
You must install the EtherCAT Coupler Unit and NX Units on a DIN Track.
The following products are recommended.
Not all of the combinations of the DIN Tracks and End Plates listed above are possible.
Confirm applicability of the combinations in the following table.
6-1-2 Preparations for Installation
Name Model Manufacturer Remarks
35-mm DIN
Track
PFP-50N OMRON Corporation • Length: 50 cm
• Material: Aluminum
• Surface treatment: Insulated
PFP-100N OMRON Corporation • Length: 100 cm
• Material: Aluminum
• Surface treatment: Insulated
NS 35/7,5 PERF Phoenix Contact • Length: 75.5, 95.5, 115.5, or 200 cm
• Material: Steel
• Surface treatment: Conductive
NS 35/15 PERF Phoenix Contact • Length: 75.5, 95.5, 115.5, or 200 cm
• Material: Steel
• Surface treatment: Conductive
End Plate PFP-M OMRON Corporation Two End Plates are required for each
EtherCAT Slave Terminal.
CLIPFIX 35 Phoenix Contact Two End Plates are required for each
EtherCAT Slave Terminal.
DIN Track model
PFP-M
(OMRON)
CLIPFIX 35
(Phoenix Contact)
PFP-50N Possible. Possible.
PFP-100N Possible. Possible.
NS 35/7,5 PERF Possible. Possible.
NS 35/15 PERF Not possible. Possible.
