Omron NX-ECC201 User Manual

11 EtherCAT Coupler Unit Functions
11 - 20
NX-series EtherCAT Coupler Unit User’s Manual (W519)
11-6 Clearing All Memory
This section describes how to clear all memory in the EtherCAT Slave Terminals.
The clear all memory function initializes various setting information in the EtherCAT Slave Terminal to
the default settings, such as the Unit configuration information and the I/O allocation information.
You can use this function on the Sysmac Studio to initialize various setting information.
You can specify the scope of the memory to clear from the following.
• EtherCAT Slave Terminal
• EtherCAT Coupler Unit
•NX Units
Additional Information
Even if you clear all memory on the NJ-series CPU Unit, the memory in the EtherCAT Slave
Terminal is not cleared.
The function clears the following data in the EtherCAT Slave Terminal.
11-6-1 Introduction
11-6-2 Details on Clearing All Memory
Specifying the Scope of Memory to Clear
Scope of Data to Clear and State of Memory After It Is Cleared
Data Status after clear all memory operation
Unit configuration information This data is set to the default settings.
If you turn ON the Unit power supply immediately after the memory all clear
process is completed, the Slave Terminal starts based on the actual Unit
configuration information.
I/O allocation information This data is set to the default settings.
Unit operation settings This data is set to the default settings.
Unit application data Refer to the manual for each NX Unit for the operating specifications when
the memory all clear function is used on NX Units that have Unit application
data.
Event logs Event logs are cleared if you select the Clearing event log Option when you
execute the memory all clear function.
