Omron NX-ECC201 User Manual

11 - 23
11 EtherCAT Coupler Unit Functions
NX-series EtherCAT Coupler Unit User’s Manual (W519)
11-7 Restarting
11
11-7-3 Procedure for Restarting
Use the following procedure to restart all of the Units in the Slave Terminal.
Use the Sysmac Studio.
1 Go online, right-click the EtherCAT Coupler Unit in the Edit Slave Terminal Configuration Tab
Page, and select Restart.
A Restart Confirmation Dialog Box is displayed.
2 Click the Yes Button.
After the Units are restarted, a Restart Completion Dialog Box is displayed.
11-7-3 Procedure for Restarting
