13 Troubleshooting
13 - 12
NX-series EtherCAT Coupler Unit User’s Manual (W519)
13-3 Checking for Errors and Trouble-
shooting on the Sysmac Studio
Error management on the NX Series is based on the methods used for the NJ-series Controllers.
This allows you to use the Sysmac Studio to check the meanings of errors and troubleshooting proce-
dures.
When an error occurs, you can place the Sysmac Studio online to the Controller or the EtherCAT Cou-
pler Unit to check current Controller errors and the log of past Controller errors.
The methods that are used to check errors depend on the Controller you use.
Refer to the NJ-series Troubleshooting Manual (Cat. No. W503) for information on NJ-series error man-
agement methods.
Refer to the NJ-Series Sysmac Studio Version 1 Operation Manual (Cat. No. W504) for details on trou-
bleshooting with the Sysmac Studio.
If you cannot check the error on the Sysmac Studio, check the error by following the flow outlined in
13-10 Troubleshooting Flow When Errors Occur on page 13-51.
Additional Information
Checking Errors in an EtherCAT Slave Terminal with an NS-series PT
You can use an NS-series PT to view current errors on the EtherCAT Coupler Unit errors and
some of the NX Units as well as information on the NX Units in which current errors occurred.
You cannot use it to check event logs and details on current errors in the NX Units.
13-3-1 Checking for Errors from the Sysmac Studio
Controller
used
Sysmac Studio
connection
Scope of check Remarks
NJ-series
Controller
NJ-series CPU Unit You can check the errors that are
managed by the Controller. This
includes errors for the connected
EtherCAT Slave Terminals.
You cannot check errors if there is
a fatal error in the CPU Unit.
EtherCAT Coupler
Unit
You can check the errors that are
managed by the EtherCAT Coupler
Unit. You can check errors in the
EtherCAT Coupler Unit to which the
Sysmac Studio is connected, and
errors in the NX Units that are con-
nected after the EtherCAT Coupler
Unit.
• You can check errors in the Slave
Terminals even if there is a fatal
error in the CPU Unit.
• You cannot check errors if there
is a fatal error in the EtherCAT
Coupler Unit.
• Some errors in the NX Units can-
not be checked if a fatal error
occurs in that NX Unit.
*1
*1. On NX Units that manage their own errors, current errors cannot be checked after a fatal error occurs in that
NX Unit. On NX Units that record their own event logs, the error log cannot be checked after a fatal error occurs
in that NX Unit.
Other control-
lers
EtherCAT Coupler
Unit
Same as above. Same as above.
