Omron NX-ECC201 User Manual

4 - 13
4 Part Names and Functions
NX-series EtherCAT Coupler Unit User’s Manual (W519)
4-6 DIN Track Contact Plate
4
4-6 DIN Track Contact Plate
There is a DIN Track contact plate in the section on the back of the EtherCAT Coupler Unit that comes
into contact with the DIN Track.
This plate is connected internally to the functional ground terminal on EtherCAT Coupler Unit. This
means that the functional ground terminal will be electrically connected to the DIN Track.
For details, refer to 7-2-3 Grounding the EtherCAT Slave Terminal on page 7-9.
DIN Track contact plate
DIN Track
contact plate
Functional ground
terminal
Connected inside the Unit.
Unit side
