3 Specifications and Application Procedures
3 - 8
NX-series EtherCAT Coupler Unit User’s Manual (W519)
3-2-2 Details
Procedure Item Description Reference
1
Preparing for
Work
Selecting NX
Units
• Select the NX Units for I/O refreshing methods, and the
quantity and types of I/O that are required.
• 2-2-2 Types of
NX Units on
page 2-6
• 10-3-3 Selecting
NX Units on
page 10-7
Confirming Suit-
ability of Slave
Terminal Speci-
fications
Confirm that the following specific restrictions for the Slave
Terminal are met.
• Number of NX Units
• Send/receive PDO data sizes
• Design conditions for the NX Unit power supply and I/O
power supply
• Installation orientation
• 3-1 Specifica-
tions on page 3-2
• Section 5
Designing the
Power Supply
System
• 6-1-3 Installation
Orientation on
page 6-8
2
Making Hard-
ware Settings
and Wiring the
Slave Terminal
Setting the
Node Address
Set the node address of the EtherCAT Coupler Unit with the
hardware switches. You can also use the Sysmac Studio to
set the node address with software settings. To use software
settings, set the hardware switches to 000, and then mount
and wire the EtherCAT Coupler Unit. When you go online in
step 3, follow the procedure to automatically create the
EtherCAT network configuration from the actual network
devices with the compare and merge operation. This sets the
node address to the software setting.
4-3 Hardware
Switch Settings on
page 4-9
Installation Connect the NX Units and End Cover to the EtherCAT Cou-
pler Unit and secure the Slave Terminal to a DIN Track to
install it.
6-1 Installing Units
on page 6-2
Wiring Wire the Slave Terminal.
• Connect the communications cables.
• Connect the Unit power supply.
• Connect the I/O power supply.
• Connect the ground wire.
• Connect the external I/O devices.
Section 7 Wiring
3
Creating the
EtherCAT Net-
work Configu-
ration and
Making Set-
tings as an
EtherCAT
Slave
Creating the
EtherCAT Net-
work Configura-
tion and Making
Settings as an
EtherCAT Slave
Create a project in the Sysmac Studio.
Create the EtherCAT network configuration offline.
Specifically, register the EtherCAT Coupler Unit in the net-
work configuration. Then, make the settings for the EtherCAT
Coupler Unit as an EtherCAT slave. Set the node address of
the EtherCAT Coupler Unit to the node address set in step 2.
Set other parameters as required.
If you want to use the compare and merge operation to auto-
matically create the EtherCAT network configuration online
based on the actual devices that are connected to the net-
work, you must use step 8 first to go online. After the network
configuration is created automatically, go offline and set the
other parameters.
9-2-2 Settings as
an EtherCAT Slave
on page 9-6
To Next Page
