Omron NX-ECC201 User Manual

11 - 19
11 EtherCAT Coupler Unit Functions
NX-series EtherCAT Coupler Unit User’s Manual (W519)
11-5 Event Logs
11
11-5-5 Exporting the Event Log
You can export the contents of the event log to a CSV file.
The event log for the EtherCAT Coupler Unit and NX Units is displayed as part of the Controller event
log. Use the Sysmac Studio.
1 Select Troubleshooting from the Tools Menu while online. You can also click the Trouble-
shooting Button in the toolbar.
The following Troubleshooting Dialog Box is displayed.
2 In the Select the Display Target Area of the Controller Event Log Tab Page, select the Unit for
which to export the events and click the Save Button.
The Save Dialog Box is displayed.
3 Input the file name, and then click the Save Button.
The Controller event logs are saved in CSV format.
11-5-5 Exporting the Event Log
