Omron R88D-KN series User Manual

3-39
3 Specifications
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
3-5 Reactor Specifications
3
3-5 Reactor Specifications
A Reactor is connected to the Servo Drive to suppress harmonic currents.
Select an appropriate Reactor for your Servo Drive model.
Servo Drive model
Reactor
Model
Rated
current
Inductance Weight Reactor Type
R88D-KN01H-ECT-L (For single-phase input) 3G3AX-DL2002 1.6 A 21.4 mH Approx.
0.8 kg
DC reactor
R88D-KN01L-ECT-L
R88D-KN02H-ECT-L (For single-phase input)
3G3AX-DL2004 3.2 A 10.7 mH Approx.
1.0 kg
R88D-KN02L-ECT-L
R88D-KN04H-ECT-L (For single-phase input)
3G3AX-DL2007 6.1 A 6.75 mH Approx.
1.3 kg
R88D-KN04L-ECT-L
R88D-KN08H-ECT-L
R88D-KN10H-ECT-L (For single-phase input)
3G3AX-DL2015 9.3 A 3.51 mH Approx.
1.6 kg
R88D-KN15H-ECT-L (For single-phase input) 3G3AX-DL2022 13.8 A 2.51 mH Approx.
2.1 kg
R88D-KN08H-ECT-L
R88D-KN10H-ECT-L
R88D-KN15H-ECT-L (For 3-phase input)
3G3AX-AL2025 10.0 A 2.8 mH Approx.
2.8 kg
AC reactor
R88D-KN20H-ECT-L
R88D-KN30H-ECT-L
3G3AX-AL2055 20.0 A 0.88 mH Approx.
4.0 kg
R88D-KN50H-ECT-L 3G3AX-AL2110 34.0 A 0.35 mH Approx.
5.0 kg
R88D-KN75H-ECT-L
R88D-KN150H-ECT-L
3G3AX-AL2220 67.0 A 0.18 mH Approx.
10.0 kg
R88D-KN06F-ECT-L
R88D-KN10F-ECT-L
R88D-KN15F-ECT-L
3G3AX-AL4025 5.0 A 7.7 mH Approx.
2.7 kg
R88D-KN20F-ECT-L
R88D-KN30F-ECT-L
3G3AX-AL4055 10.0 A 3.5 mH Approx.
4.0 kg
R88D-KN50F-ECT-L 3G3AX-AL4110 17.0 A 1.3 mH Approx.
6.0 kg
R88D-KN75F-ECT-L
R88D-KN150F-ECT-L
3G3AX-AL4220 34.0 A 0.74 mH Approx.
10.0 kg
