8-7

8 Safety Function

G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type

8-3 Connection Examples

Connection with a Safety Controller

EDM+

EDM-

SF1-

SF1+

SF2+

SF2-

G9SP-series

Safety output

(source)

Safety output 1

Safety output 2

Safety Controller

Safety input

Test output

Safety input

EDM input

EDM output

Drive
