3 Specifications
3-16
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
Remote Outputs (R-OUT1 and R-OUT2)
• Remote Output 1 (R-OUT1) turns ON and OFF according to the ON/OFF status of bit 16 in the
Digital outputs (60FE hex).
• Remote Output 2 (R-OUT2) turns ON and OFF according to the ON/OFF status of bit 17 in the
Digital outputs (60FE hex).
• With the default settings, the output is not allocated.
Magnetic Pole Position Estimation Completion Output (CS-CMP)
• This output turns ON when the magnetic pole position estimation is completed.
• With the default settings, the output is not allocated.
These are the specifications of the external encoder that can be used in conjunction with the Servo
Drive.
*1 Set the number of pulses per magnetic pole pitch (or one cycle of electrical angle) to at least 2048 pulses.
*2 This represents the encoder speed supported on the Servo Drive. Check separately the external encoder
operation manual for its supported speed.
*3 For the external encoder signal cable, use a shielded twisted-pair cable with 0.18 mm
2
or thicker core wires.
*4 We recommend you to use a 5 V power supply with the double wiring technique to reduce the effects of a volt-
age drop if the wiring length is long.
3-1-10 External Encoder Specifications
Item Specifications
Resolution
0.01 to 10 [m/ pulse]
*1
Maximum length
Resolution x (2
30
-1) or less
Encoder type • Phase A/B, origin signal differential input
• AT573A, ST770A, and ST770AL by Mitutoyo Corporation
• SR75, SR77, SR85, and SR87 by Magnescale Co., Ltd
Supported encoder speed
*2
• Phase A/B type (90° phase difference input)
• Serial communications type
: to 4 Mpps
: to 400 Mpps
External Encoder Cable
Cable specifications : Shielded twisted-pair cable
*3
Maximum cable length : 20 m
*4
To Next Page
