Omron R88D-KN series User Manual

2 Models and External Dimensions
2-6
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
The following tables list the models of EtherCAT communications cables (recommended) and analog
monitor cables, as well as the models of peripheral devices such as External Regeneration Resistors
and Reactors.
Ethernet Category 5 (100BASE-TX) or higher (twisted-pair cable with double, aluminum tape and
braided shielding) is recommended.
2-3-2 Cable and Peripheral Device Model Tables
EtherCAT Communications Cable (Recommended)
Size x Number of cable cores
(pairs)
Recommended manufacturer Model
AWG24 x 4P Tonichi kyosan Cable, Ltd. NETSTAR-C5E SAB 0.5  4P
Kuramo Electric Co. KETH-SB
SWCC Showa Cable Systems Co. FAE-5004
AWG22 x 2P Kuramo Electric Co. KETH-PSB-OMR
Analog Monitor Cable
Name Model
Analog Monitor Cable 1 m R88A-CMK001S
Connectors
Name and applications Model
Control I/O Connector (CN1) R88A-CNW01C
External Encoder Connector (CN4) R88A-CNK41L
Safety Connector (CN8) R88A-CNK81S
Control Cables
Name Model
Connector-terminal Block Cables 1 m XW2Z-100J-B34
2 m XW2Z-200J-B34
Connector-terminal Block M3 screws XW2B-20G4
M3.5 screws XW2B-20G5
M3 screws XW2D-20G6
