10 Operation
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
10-2 Preparing for Operation
10
10-2-1 Items to Check Before Turning ON the Power Supply
10-2 Preparing for Operation
This section explains the procedure to prepare the mechanical system for operation following
installation and wiring of the motor and drive. It explains items to check both before and after turning
ON the power supply.
Check to be sure that the power supply voltage is within the ranges shown below.
• R88D-KN01L-ECT-L/-KN02L-ECT-L/-KN04L-ECT-L (Single-phase 100-VAC input)
Main circuit power supply: Single-phase 100 to 120 VAC (85 to 132) 50/60 Hz
Control circuit power supply: Single-phase 100 to 120 VAC (85 to 132) 50/60 Hz
• R88D-KN01H-ECT-L/-KN02H-ECT-L/-KN04H-ECT-L/-KN08H-ECT-L/-KN10H-ECT-L/-KN15H-ECT-L
(Single-phase/3-phase 200 VAC input)
Main circuit power supply: Single-phase/3-phase 200 to 240 VAC (170 to 264) 50/60 Hz
Control circuit power supply: Single-phase 200 to 240 VAC (170 to 264) 50/60 Hz
• R88D-KN20H-ECT-L/-KN30H-ECT-L/-KN50H-ECT-L/-KN75H-ECT-L/-KN150H-ECT-L
(3-phase 200 VAC input)
Main circuit power supply: 3-phase 200 to 230 VAC (170 to 253) 50/60 Hz
Control circuit power supply: Single-phase 200 to 230 VAC (170 to 253) 50/60 Hz
• R88D-KN06F-ECT-L/-KN10F-ECT-L/-KN15F-ECT-L/-KN20F-ECT-L/-KN30F-ECT-L/-KN50F-ECT-L/
-KN75F-ECT-L/-KN150F-ECT-L (3-phase 400 VAC input)
Main circuit power supply: 3-phase 380 to 480 VAC (323 to 528) 50/60 Hz
Control circuit power supply: 24 VDC  15%
• The main circuit power supply inputs (L1/L3 or L1/L2/L3) must be properly connected to the terminal
block.
• The control circuit power supply inputs (L1C/L2C) must be properly connected to the terminal block.
• The motor's red (U), write (V), and blue (W) power lines and the green/yellow ( ) must be properly
connected to the terminal block.
• There should be no load on the motor. (Do not connect the mechanical system.)
• The motor side power lines and the power cables must be securely connected.
• The external encoder cable must be securely connected to the external encoder connector (CN4) at
the Servo Drive.
• The cable from the Servo Drive must be securely connected to the connector at the external encoder.
10-2-1 Items to Check Before Turning ON the Power Supply
Checking Power Supply Voltage
Checking Terminal Block Wiring
Checking the Motor
Checking the External Encoder Wiring
