Omron R88D-KN series User Manual

3 Specifications
3-22
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
Through the USB connection with computer, operations such as parameter setting and changing,
monitoring of control status, checking error status and error history, and parameter saving and loading
can be performed.
Precautions for Correct UsePrecautions for Correct Use
• Use a commercially available USB cable that is shielded, equipped with a ferrite core for noise
immunity, and supports USB2.0.
The Mini B type USB cable can be used.
3-1-13 USB Connector Specifications (CN7)
Pin No. Symbol Name Function and interface
1 VBUS USB signal terminal Use this function for computer communication.
2D
3D
4  Reserved for manufacturer use Do not connect.
5 SENGND Signal ground Signal ground
