Omron R88D-KN series User Manual

9-27
9 Servo Parameter Objects
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
9-5 Interface Monitor Settings
9
9-5 Interface Monitor Settings
• Set the function and logic for general-purpose input 1 (IN1).
Refer to the Details of Control Inputs in Control Input Details on page 3-9, as well as 7-1 Sequence I/O
Signals on page 7-2.
• Set the function and logic for general-purpose input 2 (IN2).
Refer to the Details of Control Inputs in Control Input Details on page 3-9, as well as 7-1 Sequence I/O
Signals on page 7-2.
• Set the function and logic for general-purpose input 3 (IN3).
Refer to the Details of Control Inputs in Control Input Details on page 3-9, as well as 7-1 Sequence I/O
Signals on page 7-2.
• Set the function and logic for general-purpose input 4 (IN4).
Refer to the Details of Control Inputs in Control Input Details on page 3-9, as well as 7-1 Sequence I/O
Signals on page 7-2.
• Set the function and logic for general-purpose input 5 (IN5).
Refer to the Details of Control Inputs in Control Input Details on page 3-9, as well as 7-1 Sequence I/O
Signals on page 7-2.
3400 hex
Input Signal Selection 1
Setting range 0 to 00FF
FFFF hex
Unit  Default
setting
0094 9494 hex Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
3401 hex
Input Signal Selection 2
Setting range 0 to 00FF
FFFF hex
Unit  Default
setting
0081 8181 hex Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
3402 hex
Input Signal Selection 3
Setting range 0 to 00FF
FFFF hex
Unit  Default
setting
0082 8282 hex Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
3403 hex
Input Signal Selection 4
Setting range 0 to 00FF
FFFF hex
Unit  Default
setting
0022 2222 hex Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
3404 hex
Input Signal Selection 5
Setting range 0 to 00FF
FFFF hex
Unit  Default
setting
002B 2B2B hex Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
All
All
All
All
All
