5-3
5
Digital Operation Display Functions and Levels
The following figure shows the Digital Operator display hierarchy for the Inverter.
MENU
Drive Mode
Inverter can be operated and its
status can be displayed.
Quick Programming Mode
Minimum parameters required
for operation can be monitored
or set.
Advanced Programming Mode
All parameters can be moni-
tored or set.
Verify Mode
Parameters changed from the
default settings can be moni-
tored or set.
Autotuning Mode
Automatically sets motor
parameters for open-loop vec-
tor control or measures the line-
to-line resistance for V/f con-
trol.
No. Function Page
U1 Status Monitor Parameters 5-70
U2 Fault Trace
5-75
U3 Fault History 5-76
A1 Initialize Mode 5-8
A2 User-specified Setting Mode 5-9
b1 Operation Mode Selections 5-10
b2 DC Injection Braking 5-11
b3 Speed Search 5-12
b4 Timer Function 5-13
b5 PID Control 5-14
b6 Dwell Functions 5-17
b7 Droop Control 5-17
b8 Energy Saving 5-18
b9 Zero Servo Control 5-19
C1 Acceleration/Deceleration 5-20
C2 S-curve Acceleration/Deceleration 5-21
C3 Motor Slip Compensation 5-21
C4 Torque Compensation 5-23
C5 Speed Control (ASR) 5-24
C6 Carrier Frequency 5-25
d1 Preset Reference 5-26
d2 Reference Limits 5-27
d3 Jump Frequencies 5-28
d4 Reference Frequency Hold 5-28
d5 Torque Control 5-29
d6 Field Weakening 5-30
E1 V/f Pattern 5-31
E2 Motor Setup 5-32
E3 Motor 2 V/f Pattern 5-34
E4 Motor 2 Setup 5-35
F1 PG Option Setup 5-36
F2 Analog Reference Card 5-38
F3 Digital Reference Card 5-39
F6 Serial Communications Settings 5-41
H1 Multi-function Digital Inputs 5-43
H2 Multi-function Digital Outputs 5-45
H3
Multi-function Analog Inputs 5-47
H4 Multi-function Analog Outputs 5-49
H5 MEMOBUS Communications 5-50
H6 Pulse Train Input/Output 5-51
L1 Motor Overload 5-52
L2 Power Loss Ride through 5-53
L3 Stall Prevention 5-54
L4 Reference Detection 5-56
L5 Fault Restart 5-57
L6 Torque Detection 5-58
L7 Torque Limits 5-59
L8 Hardware Protection 5-60
n1 Hunting Prevention Function 5-61
n2 Automatic Frequency Regulator 5-63
n3 High-slip Braking 5-63
o1 Monitor Selection 5-64
o2 Digital Operator Functions 5-65
o3 Copy Function 5-66
S1 Speed Follower Configuration 1 5-67
S2 Speed Follower Configuration 2 5-68
T Motor Autotuning 5-68
