Omron VARISPEED F7 User Manual

5-43
5
 Terminal Function Parameters: H
Multi-function Digital Inputs: H1
* 1. The values in parentheses indicate initial values when initialized in 3-wire sequence.
Multi-function Digital Input Functions
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
H1-01
Terminal S3
function
selection
Multi-function input 1 0 to 93 24 No A A A A 400H -
Terminal S3
Sel
H1-02
Terminal S4
function
selection
Multi-function input 2 0 to 93 14 No A A A A 401H -
Terminal S3
Sel
H1-03
Terminal S5
function
selection
Multi-function input 3
0 to 78
3 (0)
*
No A A A A 402H -
Terminal S3
Sel
0 to 93
H1-04
Terminal S6
function
selection
Multi-function input 4
4 (3)
*
No A A A A 403H -
Terminal S3
Sel
H1-05
Terminal S7
function
selection
Multi-function input 5 0 to 93
6 (4)
*
No A A A A 404H -
Terminal S3
Sel
Setting
Value
Function
Control Methods
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
0 3-wire sequence (Forward/Reverse Run command) Yes Yes Yes Yes 6-13
1 Local/Remote selection (ON: Operator, OFF: Parameter b1-01/b1-02 setting) Yes Yes Yes Yes 6-68
2 Operation Source Option Card/Inverter (OFF: Option Card, ON: b1-01/b1-02) Yes Yes Yes Yes 6-75
3
Multi-step speed reference 1
If H3-09 is set to 2, this function is combined with the master/auxiliary speed
switch.
Yes Yes Yes Yes 6-10
4 Multi-step speed reference 2 Yes Yes Yes Yes 6-10
5 Multi-step speed reference 3 Yes Yes Yes Yes 6-10
6 Jog frequency command (higher priority than multi-step speed reference) Yes Yes Yes Yes 6-10
7 Accel/decel time selection 1 Yes Yes Yes Yes 6-21
8 External baseblock NO (NO contact: Baseblock at ON) Yes Yes Yes Yes 6-68
9 External baseblock NC (NC contact: Baseblock at OFF) Yes Yes Yes Yes 6-68
A
Acceleration/deceleration ramp hold (ON: Acceleration/deceleration stopped, fre-
quency is hold)
Yes Yes Yes Yes 6-70
B OH2 alarm signal input (ON: OH2 will be displayed) Yes Yes Yes Yes 6-69
C Multi-function analog input A2 disable/enable (ON: Enable) Yes Yes Yes Yes 6-69
