 Field Forcing
The field forcing function controls the motor flux and compensates the flux establishment delay of the motor.
Thereby it improves the motor responsiveness on changes in the speed reference or the load.
Field forcing is applied during all operation conditions except DC Injection.
Using parameter d6-04 a field forcing limit can be applied. A setting of 100% is equal to the no-load current
set in parameter E2-03.
Related Parameters
 Setting Motor 1 Parameters
In vector control method, the motor parameters are set automatically during autotuning. If autotuning does not
complete normally, set them manually.
Related Parameters
Note:All factory-set parameters are for a standard 4-pole motor.
Parameter
No.
Name
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f with
PG
Open
Loop
Vector
Closed
Loop
Vector
d6-03 Field forcing selection 0 No No No No A
d6-04 Field forcing limit 400% No No No A A
Parameter
No.
Name
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f with
PG
Open
Loop
Vector
Closed
Loop
Vector
E2-01 Motor rated current
1.90 A
* 1
* 1. The factory setting depends on the Inverter capacity (the values for a 200 V Class Inverter of 0.4 kW is shown).
No QQQQ
E2-02 Motor rated slip
2.90 Hz
*1
No AAAA
E2-03 Motor no-load current
1.20 A
*1
No AAAA
E2-04 Number of motor poles (Number of poles) 4 poles No No Q Q Q
E2-05 Motor line-to-line resistance
9.842 Ω
*1
No AAAA
E2-06 Motor leak inductance 18.2% No No No A A
E2-07 Motor iron saturation coefficient 1 0.50 No No No A A
E2-08 Motor iron saturation coefficient 2 0.75 No No No A A
E2-10 Motor iron loss for torque compensation
14 W
*1
No A A No No
E2-11 Motor rated output power
0.40
*1
No QQQQ
