Omron VARISPEED F7 User Manual

5-67
5
 Speed Follower: S
Speed Follower Configuration 1: S1
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
S1-01
Follower
Mode Selec-
toin
Sets the Speed Follower oper-
atoin mode
0: Disabled
Follower mode is disabled
and the drive runs from the
normal frequency refer-
ence.
1: Speed - Both Directions
The drive follows the mas-
ter encoder speed in both
directions.
2: Speed - Forward Direction
The drive follows the mas-
ter encoder speed in the
forward direction only.
3: Speed - Absolute Value
The drive follows the mas-
ter encoder speed but
ignores the master encoder
direction (always forward
direction)
0 to 3 0 No Q Q Q Q 680H 5-67
Follower
Mode
S1-02
Master
encoder PPR
Sets the master drive encoder
PPR.
20 to
60000
1024 No Q Q Q Q 681H 5-67
Master PG
PPR
S1-03
Ratio
Numerator
(Upper 4
Digits)
Sets the upper 4 digits of the
primary gear ratio numerator.
0 to
9999
1000 Yes Q Q Q Q 682H 5-67
Ratio Num
High
S1-04
Ratio
Denomina-
tor (Upper 4
Digits)
Sets the upper 4 digits of the
primary gear ratio denomina-
tor
0 to
9999
1000 Yes Q Q Q Q 683H 5-67
Ratio Den
High
S1-05
Ratio
Numerator
(Lower 4
Digits)
Sets the lower 4 digits of the
primary gear ratio denomina-
tor
0 to
9999
0 Yes A A A A 684H 5-67
Ratio Num
Low
S1-06
Ratio
Denomina-
tor (Lower 4
Digits)
Sets the lower 4 digits of the
primary gear ratio denomina-
tor
0 to
9999
0 Yes A A A A 685H 5-67
Ratio Den
Low
