Omron VARISPEED F7 User Manual

2-33
2
 PG Speed Control Card Terminals and Specifications
PG-B2
The terminal specifications for the PG-B2 are given in the following table.
 PG-X2
The terminal specifications for the PG-X2 are given in the following table.
* 5 VDC and 12 VDC cannot be used at the same time.
Table 2.13 PG-B2 Terminal Specifications
Terminal No. Contents Specifications
TA1
1
Power supply for pulse generator
12 VDC (±5%), 200 mA max.
2 0 VDC (GND for power supply)
3
Pulse input terminals phase A
H: +8 to 12 V (max. input frequency: 50 kHz)
4 GND pulse input phase A
5
Pulse input terminals phase B
H: +8 to 12 V (max. input frequency: 50 kHz)
6 GND pulse input phase B
TA2
1
Pulse monitor output terminals
phase A
Open collector output, 24 VDC, 30 mA max.
2
3
Pulse monitor output terminals
phase B
Open collector output, 24 VDC, 30 mA max.
4
TA3 (E) Shield connection terminal -
Table 2.14 PG-X2 Terminal Specifications
Terminal No. Contents Specifications
TA1
1
Power supply for pulse generator
12 VDC (±5%), 200 mA max.*
2 0 VDC (GND for power supply)
3 5 VDC (±5%), 200 mA max.*
4 Pulse input terminal phase A (+)
Line driver input (RS422 level)
(maximum input frequency: 300 kHz)
5 Pulse input terminal phase A (–)
6 Pulse input terminal phase B (+)
7 Pulse input terminal phase B (–)
8 Pulse input terminal phase Z (+)
9 Pulse input terminal phase Z (–)
10 Common terminal inputs –
TA2
1 Pulse monitor output terminal phase A (+)
Line driver output (RS422 level output)
2 Pulse monitor output terminal phase A (–)
3 Pulse monitor output terminal phase B (+)
4 Pulse monitor output terminal phase B (–)
5 Pulse monitor output terminal phase Z (+)
6 Pulse monitor output terminal phase Z (–)
7 Common terminal monitor outputs –
TA3 (E) Shield connection terminal –
