Omron VARISPEED F7 User Manual

5-26
5
 Reference Parameters: d
Preset Reference: d1
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
d1-01
Frequency
reference 1
Sets the frequency reference.
0 to
FMAX
(E1-04)
*1*2
0.00 Hz Yes Q Q Q Q 280H
4-5
6-10
Reference 1
d1-02
Frequency
reference 2
Sets the frequency reference
when multi-step speed com-
mand 1 is ON for a multi-
function input.
0.00 Hz Yes Q Q Q Q 281H
4-5
6-10
Reference 2
d1-03
Frequency
reference 3
Sets the frequency reference
when multi-step speed com-
mand 2 is ON for a multi-
function input.
0.00 Hz Yes Q Q Q Q 282H
4-5
6-10
Reference 3
d1-04
Frequency
reference 4
Sets the frequency reference
when multi-step speed com-
mands 1 and 2 are ON for
multi-function inputs.
0.00 Hz Yes Q Q Q Q 283H
4-5
6-10
Reference 4
d1-05
Frequency
reference 5
Sets the frequency when
multi-step speed command 3
is ON for a multi-function
input.
0.00 Hz Yes A A A A 284H 6-10
Reference 5
d1-06
Frequency
reference 6
Sets the frequency reference
when multi-step speed com-
mands 1 and 3 are ON for
multi-function inputs.
0.00 Hz Yes A A A A 285H 6-10
Reference 6
d1-07
Frequency
reference 7
Sets the frequency reference
when multi-step speed com-
mands 2 and 3 are ON for
multi-function inputs.
0.00 Hz Yes A A A A 286H 6-10
Reference 7
d1-08
Frequency
reference 8
Sets the frequency reference
when multi-step speed com-
mands 1, 2, and 3 are ON for
multi-function inputs.
0.00 Hz Yes A A A A 287H 6-10
Reference 8
d1-09
Frequency
reference 9
Sets the frequency reference
when multi-step speed com-
mand 4 is ON for a multi-
function input.
0.00 Hz Yes A A A A 288H 6-10
Reference 9
d1-10
Frequency
reference 10
Sets the frequency reference
when multi-step speed com-
mands 1 and 4 are ON for
multi-function inputs.
0.00 Hz Yes A A A A 28BH 6-10
Reference
10
d1-11
Frequency
reference 11
Sets the frequency reference
when multi-step speed com-
mands 2 and 4 are ON for a
multi-function inputs.
0.00 Hz Yes A A A A 28CH 6-10
Reference 11
