Omron VARISPEED F7 User Manual

6-19
6
 Using an Fast Stop
Set a digital input terminal (H1-) to 15 or 17 (Fast stop) to decelerate to stop using the fast stop decelera-
tion time set in C1-09. If inputting the fast stop with an NO contact, set the multi-function digital input termi-
nal (H1-) to 15, and if inputting the fast stop with an NC contact, set the multi-function digital input
terminal (H1-) to 17.
After the fast stop command has been input, operation cannot be restarted until the Inverter has stopped. To
cancel the fast stop, turn OFF the run command and emergency stop command.
Related parameters
Multi-function Digital Inputs (H1-01 to H1-05)
Parameter
No.
Name
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f with
PG
Open
Loop
Vector
Closed
Loop
Vector
C1-09 Fast stop time 10.0 s No AAAA
Set
Value
Function
Control Methods
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
15 Fast Stop, NO contact Yes Yes Yes Yes
17 Fast Stop, NC contact Yes Yes Yes Yes
