Omron VARISPEED F7 User Manual

5-79
5
 Factory Settings that Change with the Inverter Capacity (o2-04)
200 V Class Inverters
Parame-
ter Num-
ber
Name Unit Factory Setting
- Inverter Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15
o2-04 kVA selection - 0 1 2 3 4 5 6 7 8
b8-03
Energy-saving filter time con-
stant
sec 0.50 (Open Loop vector)
b8-04 Energy-saving coefficient - 288.20 223.70 169.40 156.80 122.90 94.75 72.69 70.44 63.13
C6-02
Carrier fre-
quency
selection
Normal Duty 1-666666666
Normal Duty 2-444346634
E2-01
(E4-01)
Motor rated current A 1.90 3.30 6.20 8.50 14.00 19.60 26.60 39.7 53.0
E2-02
(E4-02)
Motor rated slip Hz 2.90 2.50 2.60 2.90 2.73 1.50 1.30 1.70 1.60
E2-03
(E4-03)
Motor no-load current A 1.20 1.80 2.80 3.00 4.50 5.10 8.00 11.2 15.2
E2-05
(E4-05)
Motor line-to-line resistance W 9.842 5.156 1.997 1.601 0.771 0.399 0.288 0.230 0.138
E2-06
(E4-06)
Motor leak inductance % 18.2 13.8 18.5 18.4 19.6 18.2 15.5 19.5 17.2
E2-10
Motor iron loss for torque com-
pensation
W 14 26 53 77 112 172 262 245 272
E2-11
(E4-07)
Motor rated output power kW 0.40 0.75 1.50 2.20 3.70 5.50 7.50 11.00 15.00
L2-02
Momentary power loss ride
through time
sec 0.1 0.1 0.2 0.3 0.5 1.0 1.0 1.0 2.0
L2-03 Min. baseblock (BB) time sec 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
L2-04 Voltage recovery time sec 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L8-02 Overheat pre-alarm level °C 95 95 95 100 95 95 95 95 90
Parame-
ter Num-
ber
Name Unit Factory Setting
- Inverter Capacity kW 18.5 22 30 37 45 55 75 90 110
o2-04 kVA selection - 9 A B C D E F 10 11
b8-03
Energy-saving filter time con-
stant
sec 0.50 (Open Loop vector) 2.00 (Open Loop vector)
b8-04 Energy-saving coefficient - 57.87 51.79 46.27 38.16 35.78 31.35 23.10 20.65 18.12
C6-02
Carrier fre-
quency
selection
Normal Duty 1-666666666
Normal Duty 2-444346634
E2-01
(E4-01)
Motor rated current A 65.8 77.2 105.0 131.0 160.0 190.0 260.0 260.0 260.0
E2-02
(E4-02)
Motor rated slip Hz 1.67 1.70 1.80 1.33 1.60 1.43 1.39 1.39 1.39
E2-03
(E4-03)
Motor no-load current A 15.7 18.5 21.9 38.2 44.0 45.6 72.0 72.0 72.0
E2-05
(E4-05)
Motor line-to-line resistance W 0.101 0.079 0.064 0.039 0.030 0.022 0.023 0.023 0.023
E2-06
(E4-06)
Motor leak inductance % 20.1 19.5 20.8 18.8 20.2 20.5 20.0 20.0 20.0
E2-10
Motor iron loss for torque com-
pensation
W 505 538 699 823 852 960 1200 1200 1200
E2-11
(E4-07)
Motor rated output power kW 18.50 22.00 30.00 37.00 45.00 55.00 75.00 90.00 110.00
L2-02
Momentary power loss ride
through time
sec2.02.02.02.02.02.02.02.02.0
L2-03 Min. baseblock (BB) time sec 1.0 1.0 1.1 1.1 1.2 1.2 1.3 1.5 1.7
L2-04 Voltage recovery time sec 0.6 0.6 0.6 0.6 0.6 1.0 1.0 1.0 1.0
L8-02 Overheat pre-alarm level °C 100 90 90 95 100 105 110 100 95
