5-77

 Factory Settings that Change with the Control Method (A1-02)

Param

eter

Num-

ber

Name Setting Range Unit

Factory Setting

V/f Control

A1-02=0

V/F with

A1-02=1

Open Loop

Vector

A1-02=2

Closed

Loop Vec-

tor

A1-02=3

b3-01 Speed search selection 0 to 3 - 2 3 2 -

b3-02 Speed search operating current 0 to 200 1% 120 - 100 -

b8-02 Energy saving gain 0.0 to 10.0 - - - 0.7 1.0

b8-03 Energy saving filter time constant 0.0 to 10.0 - - -

0.50

* 1

* 1. The factory settings are 2.00 (Open Loop Vector) / 0.05 (Closed Loop Vector) for inverters of 55 kW and larger.

0.01

C3-01 Slip compensation gain 0.0 to 2.5 - 0.0 - 1.0 1.0

C3-02

Slip compensation primary delay time con-

stant

0 to 10000 1 ms 2000 - 200 -

C4-02

Torque compensation primary delay time

constant

0 to 10000 1 ms 200 200 20 -

C5-01 ASR proportional gain 1 0.00 to 300.00 - - 0.20 - 20.00

C5-02 ASR integral time 1 0.000 to 10.000 1 ms - 0.200 - 0.500

C5-03 ASR proportional gain 2 0.00 to 300.00 - - 0.02 - 20.00

C5-04 ASR integral time 2 0.000 to 10.000 1 ms - 0.050 - 0.500

E1-07

E3-05

Mid. output frequency (VB)

0.0 to 150.0

* 2

* 2. The given setting range is valid if Heavy Duty is selected (C6-01=0, default setting). If Normal Duty 1 or 2 is selected (C6-01=1 or 2) the setting range

will be 0.0 to 400.0 Hz.

0.1 V 2.5 2.5 3.0 -

E1-08

E3-06

Mid. output frequency voltage (VB) 0.0 to 255.0 0.1 V

15.0

* 3

* 4

* 3. The setting depends also on the Inverter capacity and the setting of E1-03. The given factory setting is for a 200V class Inverter of 0.4 kW and E1-03=F.

* 4. The settins shown is for a 200 V class Inverter. The value will be double for 400 V class Inverters.

15.0

*3 *4

13.2

E1-09

E3-07

Min. output frequency (FMIN)

0.0 to 150.0

0.1 Hz

1.2

1.5

0.5 0.0
